Once the file has been loaded the importation can be done. To do so Select the desired
lines, configure the parameters (details in the following lines) and click on "Import". A pop-
up message with the summary of the importation shows up once it's been done.
Figure 6.3 File contents and Group addresses selection
[1]
[2]
+ -
EIS type
R, W, T, U
Bacnet Object
[3]
[4]
[5]
[6]
Save settings
Import
Exit
© Intesis Software S.L. - All rights reserved
This information is subject to change without notice
®
IntesisBox is a registered trademark of Intesis Software SL
1
2
3
4
5
6
File information. The information can be sorted by columns (clicking on
the header).
Once a group address its been imported it is not showed anymore
(unless the file is reloaded)
Select/deselect all the group addresses
Same functionality and restrictions as described in the corresponding
table in section 5.1.2
Number of characters from each string (GP, GS and GA names) that are
going to compose the object description
If ticked, it prevents to import already existing addresses.
If ticked, when a group address already exist it updates its EIS and
Bacnet type.
If ticked, when a group address already exist it updates the its
description
Save the current settings (file path, import parameters ...) for future
imports (only for the working project).
Transfer the selected rows (with the defined parameters) to the
LinkBoxBacnet project.
Closes the window.
