IntesisBox BACnet/IP Server - KNX

6.2 Import ETS files to LinkBoxBacnet

Group addresses (CSV format: 1/1 tab separated) and Esf files can be imported from ETS to
LinkBoxBacnet. This allows the integration of the ETS group addresses in your IntesisBox.
How to access to this functionality is explained in section 5.1.2. Both importation methods
open a new window (Figure 6.1). The only difference between them is the information
contained in the file and therefore the values that are imported in the LinkBoxBacnet
project.
To Load the file with the group addresses use the File explorer (Figure 6.2). Select the
desired file and click on "Load". The file is going to be imported and showed in the File
content section (Figure 6.3)
© Intesis Software S.L. - All rights reserved
This information is subject to change without notice
®
IntesisBox is a registered trademark of Intesis Software SL
Figure 6.1 Import ETS files window
Figure 6.2 File explorer
User's Manual r18 eng
URL http://www.intesis.com
Email info@intesis.com
tel +34 938047134
28 / 31
