SBC86808 Pentium M All-in-One Mini ITX Board User's Manual
integration, it packs provisions such as super I/Os, UXGA, LCD,
Ethernet, solid state disk, all on a single board. Unique
embedded features such as 4 serial ports (3 x RS-232,1 xRS-
232/422/485) Mini ITX bility and that allow adoption of an
extensive array of
construction of SBC86808 series allows your system to endure
the continuous operation in hostile environments where
stability and reliability
dependability of SBC86808 series are enhanced by its built-in
watchdog timer, a special industrial feature not commonly seen
on other motherboards.
Designed for the professional embedded developers, the
Pentium 4 embedded board SBC86808 Series is virtually the
ultimate one-step solution for embedded system applications.
1.1

Specifications

CPU: LGA775 for Pentium 4 and Celeron D
Chipset: Intel 915GV + ICH*6
Bus Clock: 533/800MHz
BIOS:
Phoenix-Award BIOS, Y2K compliant
4Mbit Flash, DMI, Plug and Play
SmartView for multiple LCD type selection, display
mode option and application extension features
RPL/PXE Ethernet Boot ROM
"Load Optimized Default" to backup customized
Setting in the BIOS flash chip to prevent from CMOS
battery fail
System Memory:
2*240-pin DDR2 400/533 DIMM max.
Maximum up to 2GB in dual-channel interleaved mode.
L2 Cache: integrated in CPU
Onboard IDE:
1 parallel ATA-100 as 1* 44-pin 2.0 pitch box-header.
2*STA-150 connectors
2
PC peripherals. The
are basic requirements.
industrial-grade
System
Introduction
