Sata Connector: Cn10/Cn11 - AXIOMTEK SBC86808 Series User Manual

SBC86808 Pentium
27 GND
29 Channel A D1-
31 Channel A D1+
33 GND
35 Channel A D2-
37 Channel A D2+
39 GND
CN9: LVDS Inverter Connector
PIN Description
12V
1
2 12V
5V
3
4 ENAB
GND
5
6 GND
GND
7

2.4.8 SATA Connector: CN10/CN11

PIN
1
2
3
4
5
6
7
Jumpers and Connectors
®
M All-in-One Mini ITX Board User's Manual
28 GND
30 Channel A D3-
32 Channel A D3+
34 GND
36 Channel A CLK-
38 Channel A CLK+
40 GND
Description
GND
TX+
TX-
GND
RX-
RX+
GND
19
