SBC86808 Pentium

M All-in-One Mini ITX Board User's Manual

The watchdog timer makes the system auto-reset while it stops to

work for a period. The integrated watchdog timer can be setup as

system reset mode by program.

Timeout Value Range

1 to 255

Second

Program Sample

Watchdog timer setup as system reset with 5 second of timeout

4E, 87

4E, 2D

4F, 20

4E, 07

4F, 08

4E, 30

4F, 01

4E, F5

4F, N

4E, F6

4F, M

A p p e n d i x A

Watch Dog Timer

Set WDT Funtion Enable

Logical Device 8

Activate

Set Second

N = 00 or 08

Set Value

M = 00 ~ FF
