SBC86808 Pentium M All-in-One Mini ITX Board User's Manual

2.4.1 ATX Power Connector: CN1

Pin Description
3.3V
1
3 GND
GND
5
7 GND
5VSB
9
11 3.3V
GND
13
15 GND
GND
17
19 5V

2.4.2 Parallel IDE Connector: CN2

The SBC86808 includes a PCI bus enhanced IDE controller that can
support master/slave mode and post write transaction mechanisms
with 64-byte buffer and master data transaction.
44-pin IDE Interface Connector:
Pin Description
1 Reset #
4 Data 8
7 Data 5
10
Data 11
13 Data 2
16 Data 14
19 GND
14
Pin Description
3.3V
2
4 5V
5V
6
8 PW_OK
12V
10
12 -12V
PS_ON
14
16 GND
-5V
18
20 5V
Pin Description
2 GND
5 Data 6
8 Data 10
11
Data 3
14 Data 13
17 Data 0
20 No connector
Jumpers and Connectors
Pin Description
3 Data 7
6 Data 9
9 Data 4
12
Data 12
15 Data 1
18 Data 15
21 No connector
