SBC86808 Pentium M All-in-One Mini ITX Board User's Manual
CMOS Setup Utility-Copyright © 1984-2001 Award Software
USB Controller
USB 2.0 Controller
USB Keyboard Support
USB Mouse Support
AC97 Audio
Hance Rapid Watchdog
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
BIOS Setup Utility-Copyright © 1984-2001 Award Software
Onboard FDC Controller
Onboard Serial Port 1
Onboard Serial Port 1
UART Mode Select
Red, TxD Active
IR Transmission Delay
UR2 Duplex Mode
Use IR Pins
Onboard Parallel Port
Parallel Port Mode
EPP Mode Select
ECP Mode Use DMA
ICH Serial Port 1
ICH Serial Port 1 Use IRQ
ICH Serial Port 2
ICH Serial Port 2 Use IRQ
PWRON after power fail
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
IDE Primary/Secondary Master/Slave PIO
The four IDE PIO (Programmed Input/Output) fields let you set a
PIO mode (0-4) for each of the four IDE devices that the onboard
IDE interface supports. Modes 0 through 4 provide successively
increased performance. In Auto mode, the system automatically
determines the best mode for each device. The options available
are Auto, Mode 0, Mode 1, Mode 2, Mode 3, and Mode 4.
IDE Primary/Secondary Master/Slave UDMA
46
On board Device
Enable
Enabled
Disabled
Disabled
Auto
0
Super IO Device
Enabled
3F8/IRQ4
2F8/IRQ3
Normal
Hi,Lo
Enabled
Half
IR-Rx2Tx2
378/IRQ7
SPP
EEP1.7
3
3E8
IRQ10
2E8
IRQ11
OFF
Menu Level
Menu Level
Award BIOS Utility
