SBC86808 Pentium

M All-in-One Mini ITX Board User's Manual

Parallel Port Mode

Select an operating mode for the onboard parallel (printer) port.

Select Normal unless your hardware and software require one of

the other modes offered in this field. The options available are

EPP1.9, ECP, SPP, ECPEPP1.7, and EPP1.7.

ECP Mode Use DMA

Select a DMA channel for the parallel port for use during ECP

mode.

Award BIOS Utility
