4.10 PnP/PCI Configuration Setup

This section describes configuring the PCI bus system. PCI, or
Personal Computer Interconnect, is a system which allows I/O
devices to operate at speeds nearing the speed the CPU itself
uses when communicating with its own special components.
This section covers some very technical items and it is strongly
recommended that only experienced users should make any
changes to the default settings.
CMOS Setup Utility-Copyright © 1984-2001 Award Software
Reset Configuration Data
Resources Controlled By
►IRQ Resources
PCI/VGA Palette Snoop
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
PNP OS Installed
Select Yes if the system operating environment is Plug-and-Play
aware (e.g., Windows 95). The default value is "No".
Reset Configuration Data
Normally, you leave this field Disabled. Select Enabled to reset
Extended System Configuration Data (ESCD) when you exit
Setup or if you have installed a new add-on and the system
reconfiguration has caused such a serious conflict that the
operating system can not boot. The options available are Enabled
and Disabled.
Award BIOS Utility
®
M All-in-One Mini ITX Board User's Manual
PnP/PCI Configurations
Disabled
Auto (ESCD)
Press Enter
Disabled
Item Help
Menu Level
Select Yes if you are
using a Plug and play
Mini ITXble operating
system select No if
you need the BIOS to
configure non-boot
devices
55
