SBC86808 Pentium
Compact Flash Socket:
One Compact Flash Type II Socket(Optional)
Onboard Multi I/O:
One floppy port (Optional)
3 x RS-232, 1x RS-232/422/485
One LPT port.
USB Interface: 4 USB ports with fuse protection and
Real Time Clock: Integrate Intel
Watchdog Timer:
1~255 seconds; up to 255 levels
Graphics/Streaming:
Integrate Intel
Unified Memory Architecture shares system memory
up to 128MB
Single display mode maximum resolutions:
CRT: 1600 x1200 @ 60Hz
LVDS LCD: 1600 x 1200
DualView display mode:
CRT: 1600 x1200 @60 Hz
LVDS LCD: 1600 x 1200
LCD backlight control supported
Ethernet:
One Intel 82562GZ Fast Ethernet
optional Intel 82573E Gigabit
Wake On LAN (via ATX power supply)
Equipped with RJ-45 interface
Audio:
Realtek AC'97 codec audio
MIC-in, Line-out
Power Management:
Introduction
®
M All-in-One Mini ITX Board User's Manual
complies with USB Spec. Rev. 2.0
ICH*6
®
915GV
®
ACPI (Advanced Configuration
and Power Interface)
3
