2.4.3 Printer Port Connector: CN3

2 4 6 8 10 12
1 3 5 7 9 11
Pin Description
1 Strobe#
3 Data 0
5 Data 1
7 Data 2
9 Data 3
11 Data 4
13 Data 5
15 Data 6
17 Data 7
19 Acknowledge#
21 Busy
23 Paper Empty#
25 Printer Select
