SBC86808 Pentium M All-in-One Mini ITX Board User's Manual

2.3.8 COM3 Mode Select: JP10

COM2-3
*Pin 10=DCD
*Pin 10=5V
*Pin 18=RI
*Pin 18=+12V

2.3.9 COM4 Mode Select: JP6

CN16
*Pin 1=DCD
*Pin 1=5V
*Pin 8=RI
*Pin 8=+12V
2.3.10 Keyboard & Mouse Power Selection: JKB1
Options
5V
5VSB
12

JP10

JP10
Short 3-5(default)
Short 1-3
Short 4-6(default)
Short 2-4

JP6

Short 3-5(default)
Short 1-3
Short 4-6(default)
Short 2-4
Settings
Short 1-2(default)
Short 2-3
Jumpers and Connectors
JP6
JKB1
