2.3.1 CMOS Clear Jumper: JP1

Options
Normal
Clear CMOS

2.3.2 LVDS Voltage Setting : JP2

SBC86808 supports 3.3V or +5V flat panel displays. Configure the
jumper JP2 to the appropriate voltage of the flat panel
VDDM
3.3V
5V

2.3.3 Compact Flash Power: JP3

Options
3.3V
5V

2.3.4 Compact Flash Master/Slave Selection: JP4

Options
Slave
Master

2.3.5 COM1 Mode Select: JP11

VCOM1
10
Settings
Short 1-2 (default)
Short 2-3
Settings
Short 1-2 (default)
Short 2-3
Settings
Short 1-2(default)
Short 2-3
Settings
Short 1-2 (default)
Short 2-3
JP11
Jumpers and Connectors
JP1
1 2 3
JP2
1 2 3
JP3
1 2 3
JP4
1 2 3
