Table 22. Power losses and required cooling air for the Active Front End units
Type
NXA_0261 5
NXA_0170 6
NXA_0460 5
NXA_0325 6
NXA_1300 5
NXA_1030 6
5
Figure 35. Cooling airflow for the FI13 unit
Heat dissipation
Cooling air required
(W)
3540
3320
6160
6070
17920
19050
Minimum air holes on
switchgear (input and output)
3
(m
/h)
1150
1400
4200
Tel. +358 (0) 201 2121 • Fax +358 (0)201 212 205
Installation
2
(mm
)
50000
60000
180000
