Vacon NX Active Front End User Manual page 38

vacon • 36
4.11.2.2 DC fuses
Table 12. Ferraz Shawmut DC fuse selection, mains voltage 465–800 Vdc
Module
Type
NXA_0261 5
AFE NXA_0460 5
NXA_1300 5
Table 13. Bussman DC fuse selection, mains voltage 465–800 Vdc
Module
Type Code
NXA_0261 5
AFE NXA_0460 5
NXA_1300 5
NOTE! All fuses are flush-end type. If some other type is needed, please contact Vacon.
4.11.3 Fuses; mains voltage 525–690 V
4.11.3.1 AC fuses
Table 14. Ferraz Shawmut AC fuse selection, mains voltage 525–690 Vac
Module
Type
NXA_0170 6
AFE NXA_0325 6
NXA_1030 6
NOTE! Fuses for FI9 and FI10 are blade type and for FI13 flush-end type. If some other type is needed, please
contact Vacon.
Table 15. Bussman AC fuse selection, mains voltage 525–690 Vac
Module
Type
NXA_0170 6
AFE NXA_0325 6
NXA_1030 6
NOTE! All fuses are blade type. If some other type is needed, please contact Vacon.
4
Code Frame
FI9
FI10
FI13
Frame
FI9
FI10
FI13
Code Frame
FI9
FI10
FI13
Code Frame
FI9
FI10
FI13
DC fuses
Ferraz Shawmut
type [aR]*
PC73UD13C500TF
PC73UD95V11CTF
PC84UD11C24CTQ
DC fuses
Bussman U
N
type [aR]* [V]
170M6562 690
170M6566 690
170M6566 690
AC fuses
Ferraz Shawmut
type [aR]*
PC71UD13C315PA
PC73UD13C630PA
PC84UD12C18CTQ
AC fuses
Bussman
type [aR]*
170M4199
170M6305
170M6305
Tel. +358 (0) 201 2121 • Fax +358 (0)201 212 205
Active Front End (AFE)
U I
N N
Size
[V] [A]
1250 500 3
950 1100 3
1100 2400 84
I
N
Size
[A]
800 3GKN/50
1250 3GKN/50
1250 3GKN/50
U I
N N
Size
[V] [A]
1250 315 1
1150 630 3
1150 1800 84
U I
N N
Size
[V] [A]
1250 400 1SHT
1250 700 3SHT
1250 700 3SHT
Q'ty
2
2
2
Q'ty
2
2
3x2
Q'ty
3
3
3
Q'ty
3
3
3x3
