Active Front End (AFE)
4.11.3.2 DC fuses
Table 16. Ferraz Shawmut DC fuse selection, mains voltage 640–1100 Vdc
Module
Type Code
NXA_0170 6
AFE NXA_0325 6
NXA_1030 6
Table 17. Bussman DC fuse selection, mains voltage 640–1100 Vdc
Module
Type Code
NXA_0170 6
AFE NXA_0325 6
NXA_1030 6
NOTE! All fuses are flush-end type. If some other type is needed, please contact Vacon.
24-hour support +358 (0)201 212 575 • Email: vacon@vacon.com
Ferraz Shawmut
Frame
type [aR]*
FI9 PC71UD13C400TF
FI10 PC73UD13C630TF
FI13 PC84UD11C20CTQ
Bussman
Frame
type [aR]*
FI9 170M4926
FI10 170M8507
FI13 170M8510
DC fuses
U I
N N
Size
[V] [A]
1250 400 1
1250 630 3
1100 2000 84
DC fuses
U I
N N
Size
[V] [A]
1250 400 1GKN/75
1250 700 3GKN/75
1100 1000 3GKN/75
vacon • 37
Q'ty
2
2
2
Q'ty
2
2
3x2
4
