Main Contactor - Vacon NX Active Front End User Manual

Active Front End (AFE)
4.13

Main contactor

If a main contactor is to be used, the types shown in Table 19 are recommended. If a contactor from
another manufacturer is used, it must be equivalent to the types shown. Further information on the
contactors shown is available from the manufacturer.
Type
A210-30-11-80
FI9
Type
A185-30-11-80
FI9
Type
AF400-30-11-70
FI10
Type
AF300-30-11-70
FI10
Type
AF1650-30-11-70
FI13
Type
AF1350-30-11-70
FI13
24-hour support +358 (0)201 212 575 • Email: vacon@vacon.com
Table 19. Recommended main contactor types
FI9 Contactor / 500 V
Contactor, 350 A/690 V, AC3 110 KW/400 V, 230 VAC-Coil
FI9 Contactor / 690 V
Contactor, 275 A/690 V, AC3 132 KW/690V, 230 VAC-Coil
FI10 Contactor / 500 V
Contactor, 600 A/500 V, AC3 200KW/400V, 100...250 V AC/DC coil
FI10 Contactor / 690 V
Contactor, 500 A/690 V, AC3 250 KW/690 V, 100...250 V AC/DC coil
FI13 Contactor / 500 V
Contactor, 1650 A/500 V, AC3 560 KW/400 V, 100...250 V AC/DC coil
FI13 Contactor / 690 V
Contactor, 1350 A/690 V, AC3 --- KW/400 V, 100...250 V AC/DC coil
