12. Adjustments

Additionally to the ecom-J2KN
functions described previously, various
adjustments can be made in the
instrument.
From the main menu select the sub-
menu "Adjustments" and confirm with
<OK>.
A selection
parameters, adjustable according to the
application, is displayed.
Place the cursor on the desired line and
press <OK> to call up or modify the
adjustment.
The modifiable parameters are:
Calibr. sensors:
-Select calibration menu ("Calibr. sensors" <OK>)
-Choose sensor with cursor keys and confirm with <OK>
-CO / NO / NO2 / SO2 etc. calibration
(Important: Span gas must get pressure-free to the instrument!)
-Flow with span gas
-Wait for stabilisation of value
-By drift press <OK>
-Set correct value with number keys
-Confirm input with <OK>
-T. Gas / T. Air calibration
-Create reference temperature
-By drift press <OK>
-Set correct value with number keys
-Confirm input with <OK>
-Pressure calibration
-Set draught sensor on 0 with <F4> key
-Create reference pressure
-By drift press <OK>
-Set correct value with number keys
-Confirm input with <OK>
pro
ecom-
J2KN
of modifiable
TECH
pro
TECH
Calibr. sensors
Re-Calibration
Unit
Second unit
Ref. O2
Quit with:
Fuel type
Set clock
Paper feed
Internal
Tightness test
