-Compare the greyness with the opacity scale.
-Input the result using the numerical keys and press <OK>.
-Repeat this procedure until all 3 soot dot analyses are completed.
The mean value will be calculated and automatically stored.
The result of the oil trace check is to be documented as follows:
-Set the cursor on the line "Oil trace".
-Input the result with <OK>
("NO", "YES" or "- - - ")
-Press <ESC> to quit the menu once all necessitated inputs have
been entered. The measurement is now completed.
Page 28
Get the probe cooled down before putting
it back in its fixation!
Soot..Oil trace
Boiler temp.:
1st Soot meas.: 1.0
2nd Soot meas.: 0.5
3rd Soot meas.: 1.5
Oil trace :
Mean value:
ecom-
J2KN
66°C
NO
1.0
pro
TECH
