11.5. Measurement record and printout

Once the gas analysis is completed, transfer the val-
ues recorded in the intermediate memory to the
Press <Print> (printer symbol) to enter
the printing menu. The sampled data
can be checked one more time („View
memory", <OK> and scroll with the
cursor keys).
The software keyboard enables the
input or correction of the 6 x 20-
character text. Select hereto „Input
text", press <OK> and input text (see
page 13).
Press „Memory -> M" and <OK> to
store the all data -if correct- in the
internal memory or on the multi-media
card. Once the transfer is completed, a
"Memory symbol" appears on the
bottom right of the display. The entered
text will only be recorded in the data
record by use of the multi-media card.
Select „Start printout" and press
<OK>) to start a printout.
Press <ESC> to turn back to the gas
analysis menu.
pro
ecom-
J2KN
Multi-Media-Card otherwise they could get
lost by switch-off of the instrument!
TECH
--ECOM-J2KN--
Start printout
View memory
Memory -> M
Insert Text
Quit with:
--ECOM-J2KN--
Start printout
View memory
Memory -> M
Insert Text
Quit with:
--ECOM-J2KN--
Start printout
View memory
Memory -> M
Insert Text
Quit with:
Memory symbol
--ECOM-J2KN--
Start printout
View memory
Memory -> M
Insert Text
Quit with:
Page 29
