8. Data record

The multi-media card enables the storage of both punctual
measurements and data logger records.
The values of punctual measurements are written in a text file
(J2KDV.txt). Those of data logger records in a csv file (J2KDL-xx.csv
/ xx = records numbered consecutively).
Both file types have the same structure and can be imported
respectively opened in Excel. See chapter „Technical Data" for data
format information. The files can be transferred on the PC using a
card reader. The following conditions must be fulfilled for using a
multimedia card:
pro
- ecom-J2KN TECH
- min. card volume 32 MB - max.32 GB (UHC)
- card formatted on 16 bit FAT or FAT32
- SD cards from SanDisk recommended
- PC with card reader
Insert the multi-media card as shown.
Take care that the card does not stand
out and hooks on.
Never pull out cards during data record - data loss
and damaging of the data carrier possible!
