8.7. Measurement record and printout

Important: Once the gas analysis is completed, transfer the val-
ues recorded in the intermediate memory on the MM card, oth-
erwise they would get lost by switch-off of the instrument!
Press <Print> (printer symbol) to enter
the printing menu. The sampled data
can be checked one more time („View
memory", <Enter> and scroll with the
cursor keys).
The software keyboard enables the
input or correction of the 6 lines text of
the plant identification. („Input text",
<Enter>, to write text, see chapter 7).
All data correct? Then press „Memory
-> M" and <Enter> to transfer them in
the internal memory or on the MM card
("Disk symbol" is shown in black in the
measurement mode). The inputted text
is taken over into the data record only
by transfer on MM card.
Select („Start printout" and <Enter>)
to print out the data.
Press <ESC> to turn back to the gas
analysis mode.
The functions
„Memory -> M" and „Input text" can
also be selected out of the measure-
ment mode with <Enter>.
ecom-EN2
„View memory",
--ECOM-EN2--
Start printout
View memory
Memory -> M
Input text
↑↓ ↑↓
↑↓ ↑↓
Select :
--ECOM-EN2--
Start printout
View memory
Memory -> M
Input text
↑↓ ↑↓ ↑↓ ↑↓
Select :
--ECOM-EN2--
Start printout
View memory
Memory -> M
Input text
↑↓ ↑↓
↑↓ ↑↓
Select :
--ECOM-EN2--
Start printout
View memory
Memory -> M
Input text
↑↓ ↑↓
↑↓ ↑↓
Select :
↵
↵
↵
↵
Page 23
