8.7. Measurement record and printout

Inportant: Once the gas analysis is completed, transfer the values
recorded in the intermediate memory on the MM card, otherwise
they would get lost by switch-off of the instrument!
Press <Print> (printer symbol) to enter
the printing menu. The sampled data can
be checked one more time („View
memory", <Enter> and scroll with the
cursor keys).
The software keyboard enables the input
or correction of the 6 lines text of the plant
identification. („Input text", <Enter>, to
write text, see page 13).
All data correct? Then press „Memory -
> M" and <Enter> to transfer them in the
internal memory or on the MM card
("Disk symbol" is shown in black in the
measurement mode). The inputed text is
taken over into the data record only by
transfer on MM card.
Select („Start printout" and <Enter>) to
print out the data.
Press <ESC> to turn back to the gas
analysis mode.
The functions „View memory",
„Memory -> M" and „Input text" can
also be selected out of the measurement
mode with <Enter>.
Page 20
-- ECOM-EN2 --
Start printout
View memory
Memory -> M
Input text
↑↓
Select :
-- ECOM-EN2 --
Start printout
View memory
Memory -> M
Input text
↑↓
Select :
-- ECOM-EN2 --
Start printout
View memory
Memory -> M
Input text
↑↓
Select :
-- ECOM-EN2 --
Start printout
View memory
Memory -> M
Input text
↑↓
Select :
