The CN25 has lower double-deck connector for USB 3.0 port 1 and USB 2.0 port 3.
Pins LAN1 Signals
L1 MDI0+
L2 MDI0-
L3 MDI1+
L4 MDI1-
A 100 LAN LED (Green)/1000 LAN LED (Orange)
B Active LED (Yellow)
Pins USB 3.0 Signals
USB_VCC
1
(+5V standby power)
2 USB_Data0-
3 USB_Data0+
4 GND
5 SSRX1-
6 SSRX1+
7 GND
8 SSTX1-
9 SSTX1+
Jumper & Connector Settings
Pins LAN1 Signals
L5 MDI2+
L6 MDI2-
L7 MDI3+
L8 MDI3-
Pins USB 2.0 Signals
+5V standby power
1
2 USB D1-
3 USB D1+
4 Ground (GND)
