Installation of Express Mini Card

Step 1 Turn off the system, and unplug the power adaptor.

Step 2

There are eight screws on the top heatsink are used to fasten

the heatsink to the chassis.

Step 3 Remove the top cover.

Step 4 Locate Express Mini card slot within the red line marked.

Step 5 Slide Mini Card into Mini Card slot with caution and fasten

screw of Express Mini Card.

Step 6 Assembly the top cover back and fasten all screws.

Note: Please refer to the user's manual to get more detail information.

Version A1 Jan 2017

Printed in Taiwan

9416K640000E

eBOX640-500-FL Quick Installation Guide

System Unit x 1

DVD/CD x 1 (for Driver & Manual)

Quick Installation Guide x 1

Screw pack x 1

3-pin phoenix type connector

HDD bracket x 2

(P=3.81mm) x 1

Thermal Grease x 1

Foot pad x 4

Do not try to apply power to the system if any damaged components.

Dimensions

Version A1 Jan 2017

Printed in Taiwan

9416K640000E
