Specifications
Table 8.18 Transformer Fuse (Line Contactor)
Table 8.19 Soft Charge Fuses

8.5 General Torque Tightening Values

For fastening hardware described in this manual, use the torque values in Table 8.20. These values are not intended for
fastening IGBTs. See the instructions included with those replacement parts for correct values.
Shaft Size
M4
M5
M6
8
8
M8
M10
M12
Table 8.20 Torque Values
100
Frame size
D, E, F
Frame size
D, E, F
Driver Size Torx/Hex [mm]
T-20/7
T-25/8
T-30/10
T-40/13
T-50/17
18/19
Danfoss A/S © 10/2015 All rights reserved.
®
VLT
AQUA Drive FC 202 Low Harmonic Drive
Bussmann PN
FNQ-R-3
Bussmann PN
FNQ-R-1
Rating
3 A, 600 V
Rating
1 A, 600 V
Torque [Nm]
1.0
2.3
4.0
9.6
19.2
19
Torque [in-lbs]
10
20
35
85
170
170
MG21B322
