1.1.1 Specifications

Cellular Modem
Cellular Technology
Frequency/Bands
Max Downlink Speeds
Max Uplink Speeds
Activation
Security
Physical
Enclosure
Dimensions
(H x W x D)
Shock
Vibration
Ethernet Port
Serial Port
Antenna Ports
Weight
Enclosure
Environmental
Operating Temperature
Humidity
External Power
Peak Power Consumption
Page 10 of 137
LTE, GSM, UMTS/HSPA+, GPRS, EDGE, CDMA
ICX35-HWC-A:
Freq: 700/800/850/900/1700/1800/1900/2100 MHz
HSPA and HSPA+ Bands: 1,2,4,5,8
LTE Bands: 2,4,5,13,17,25
Quad-band EDGE/GPRS/GSM
CDMA/EVDO Bands: BC0, BC1, BC10
ICX35-HWC-E:
Freq: 800/850/900/1800/1900/2100/2600 MHz
HSPA and HSPA+ Bands: 1,2,5,8
LTE Bands: 1,3,7,8,20
Quad-band EDGE/GPRS/GSM
Up to 100 Mbps maximum (network dependent)
Up to 50 Mbps maximum (network dependent)
SIM Slot
OpenVPN client, IPSec client, IP Address Filtering
Extruded aluminum with DIN clip
5.52 x 2.06 x 4.37 in
14.01 x 5.24 x 11.09 cm
IEC 60068-2-27; 20G @ 11ms (Operational)
IEC 60068-2-27; 30G @ 11ms (Non-Operational)
IEC 60068-2-6; 10G, 10 to 150 Hz
(1) 10/100 Base-T, RJ45 connector
(1) DB9 female (serial tunneling & encapsulation)
(2) Female RP-SMA connector
Antennas sold separately
14.5 oz (411 g)
Extruded aluminum with DIN clip
IEC 60068 -22°F to +158°F (-30°C to +70°C)
IEC 60068-30 5% to 95%, with no condensation
10 to 30 VDC
< 6W
ICX35-HWC ♦ Industrial Cellular Gateway
ProSoft Technology, Inc.
October 26, 2018
3G/4G LTE
