- Page 1 ProLinx-HART ProLinx Gateway HART Master with Analog I/O October 13, 2011 DRIVER MANUAL...
-
Page 2: Your Feedback Please
® ProSoft Technology Product Documentation In an effort to conserve paper, ProSoft Technology no longer includes printed manuals with our product shipments. User Manuals, Datasheets, Sample Ladder Files, and Configuration Files are provided on the enclosed CD-ROM in ® Adobe Acrobat Reader file format (.PDFs). -
Page 3: Important Installation Instructions
32K maximum HTML page size (previously limited to 16K) To upgrade a previously purchased Series C model Contact your ProSoft Technology distributor to order the upgrade and obtain a Returned Merchandise Authorization (RMA) to return the unit to ProSoft Technology. -
Page 4: Plx Markings
PLX Markings Label Markings ATEX <Ex> II 3 G Ex nA IIC T4 -20° C <= Ta <= 50° C II – Equipment intended for above ground use (not for use in mines). 3 – Category 3 equipment, investigated for normal operation only. G –... -
Page 5: Table Of Contents
ProLinx-HART ♦ ProLinx Gateway Contents HART Master with Analog I/O Driver Manual Contents Your Feedback Please ........................2 How to Contact Us ..........................2 ® ProSoft Technology Product Documentation ..................2 Important Installation Instructions ....................... 3 ® ProLinx Products Warnings ....................... 3 ProLinx Gateways with Ethernet Ports .................... - Page 6 Contents ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O 3.3.3 Enable ........................32 3.3.4 Float DB Address ....................33 3.3.5 Poll Interval ......................33 3.3.6 FP Word Count ....................... 33 3.3.7 Swap Code ......................33 3.3.8 Short Address ......................33 3.3.9...
- Page 7 ProLinx-HART ♦ ProLinx Gateway Contents HART Master with Analog I/O Driver Manual COMMAND 44 - Write PV Units ....................66 COMMAND 45 - Trim DAC Zero ....................67 COMMAND 46 - Trim DAC Gain ....................68 COMMAND 47 - Write Transfer Function ..................69 COMMAND 48 - Read Additional Transmitter Status ..............
- Page 8 Contents ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O Page 8 of 104 ProSoft Technology, Inc. October 13, 2011...
-
Page 9: Start Here
ProLinx-HART ♦ ProLinx Gateway Start Here HART Master with Analog I/O Driver Manual Start Here In This Chapter System Requirements ................10 Package Contents ................. 11 Mounting the Gateway on a DIN-rail ............. 12 Connecting Power to the Unit ..............13 Installing ProSoft Configuration Builder Software ........ -
Page 10: System Requirements
ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O System Requirements The ProSoft Configuration Builder configuration software for the ProLinx-HART module requires the following minimum hardware and software components: ® Pentium II 450 MHz minimum. Pentium III 733 MHz (or better) recommended... -
Page 11: Package Contents
HART Master with Analog I/O Driver Manual Package Contents The following components are included with your ProLinx-HART module, and are all required for installation and configuration. Important: Before beginning the installation, please verify that all of the following items are present. -
Page 12: Mounting The Gateway On A Din-Rail
Start Here ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O Mounting the Gateway on a DIN-rail ProLinx 5000/6000 Series module Page 12 of 104 ProSoft Technology, Inc. October 13, 2011... -
Page 13: Connecting Power To The Unit
ProLinx-HART ♦ ProLinx Gateway Start Here HART Master with Analog I/O Driver Manual Connecting Power to the Unit WARNING: Ensure that you do not reverse polarity when applying power to the module. This will cause damage to the module’s power supply. -
Page 14: Installing Prosoft Configuration Builder Software
You can always get the newest version of ProSoft Configuration Builder from the ProSoft Technology website. To install ProSoft Configuration Builder from the ProSoft Technology website Open your web browser and navigate to http://www.prosoft-technology.com/pcb Click the link at the Current Release Version section to download the latest version of ProSoft Configuration Builder. -
Page 15: Functional Overview
ProLinx-HART ♦ ProLinx Gateway Functional Overview HART Master with Analog I/O Driver Manual Functional Overview In This Chapter HART Channels ..................16 Functional Specifications - HART Analog ..........17 Module Internal Database ..............20 The HART Master + Analog I/O Protocol exists in 4 and 8 channel implementations. This... -
Page 16: Hart Channels
Functional Overview ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O HART Channels The ProLinx module supports the HART protocol as a Master on up to 4 channels per interface card, with one or two cards per gateway. Each channel is individually configurable. -
Page 17: Functional Specifications - Hart Analog
ProLinx-HART ♦ ProLinx Gateway Functional Overview HART Master with Analog I/O Driver Manual Functional Specifications - HART Analog The HART Analog Protocol exists in 4 and 8 channel implementations. This driver can be configured on an individual channel basis to operate as a HART Master Station and supports all the available HART commands including Universal, Common Practice and Device Specific Commands. - Page 18 Functional Overview ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O HART Commands supported Universal Command Set Read Unique Identifier Read Primary Variable Read Current And Percent Of Range Read Dynamic Variables Write Polling Address Read Unique Identifier Associated With Tag...
- Page 19 ProLinx-HART ♦ ProLinx Gateway Functional Overview HART Master with Analog I/O Driver Manual Common Practice Command Set Read Transmitter Variables Write Damping Value Write Range Values Set Upper Range Value Set Lower Range Value Reset Configuration Changed Flag EEprom Control...
-
Page 20: Module Internal Database
Functional Overview ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O Module Internal Database The internal database is central to the functionality of the module. This database is shared between all the ports on the module and is used as a conduit to pass information from one device on one network to one or more devices on another network. -
Page 21: Hart Command List
ProLinx-HART ♦ ProLinx Gateway Functional Overview HART Master with Analog I/O Driver Manual 2.3.2 HART Command List The HART Command List specifies the commands to be executed to the HART devices connected to a channel. A HART command can be seen as an outgoing message to the HART devices that provides Write Data for a specific command or a response message that carries process data (Read Data) back to the module. - Page 22 Functional Overview ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O With the auto-poll feature enabled, the module automatically generates the following HART commands and stores the data in the module's database at the user-specified location: Description Read Unique Identifier...
- Page 23 ProLinx-HART ♦ ProLinx Gateway Functional Overview HART Master with Analog I/O Driver Manual DB Byte Type Description Byte Data Use of Data Offset Source byte Transducer limits and min span CMD 14 Info units code byte PV alarm selection code...
-
Page 24: Auto-Poll Disabled Mode
Functional Overview ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O The following topics describe the modes of module operation. Auto-Poll Disabled Mode If the auto-polling feature is disabled (Auto-Poll Code = N), the module functions as shown in the following diagram: Only the user commands are executed and all data is placed in and sourced from the module's internal database. - Page 25 ProLinx-HART ♦ ProLinx Gateway Functional Overview HART Master with Analog I/O Driver Manual When the point-to-point mode of auto-polling is enabled (Auto-Poll Code = P), the following diagram applies to the channel operation: ProSoft Technology, Inc. Page 25 of 104...
- Page 26 Functional Overview ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O Page 26 of 104 ProSoft Technology, Inc. October 13, 2011...
-
Page 27: Hart Protocol Configuration
ProLinx-HART ♦ ProLinx Gateway HART Protocol Configuration HART Master with Analog I/O Driver Manual HART Protocol Configuration In This Chapter [Analog HART Card x] ................28 [HART PORT x] ..................29 [HART PORT x COMMANDS] ............... 31 Using the CommonNet Data Map ............37 Downloading a File from PC to the Module ........... -
Page 28: Analog Hart Card X]
HART Protocol Configuration ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O [Analog HART Card x] 3.1.1 Database Register -1, 0 to 3984 This parameter sets the database address in the module where the following values will be placed:... -
Page 29: Hart Port X]
ProLinx-HART ♦ ProLinx Gateway HART Protocol Configuration HART Master with Analog I/O Driver Manual [HART PORT x] The configuration file sections [HART PORT 0] through [HART PORT 3] (for 4 channel modules) or [HART PORT 0] through [HART PORT 7] (for 8 channel modules) set HART channel communication parameters, define the protocol specific parameters, and set the command list parameters. -
Page 30: Command Count
HART Protocol Configuration ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O 3.2.6 Command Count 0 to 99 This parameter sets the number of user commands to be utilized. The first command in the list is always reserved for the auto-poll command so the user should configure this value considering one command for the auto-poll. -
Page 31: Hart Port X Commands]
HART channels. The module supports up to 100 commands per channel. 3.3.1 Command List Overview The ProLinx-HART module uses a command list to interface with HART slave devices. The commands in the list specify the slave device to be addressed the function to be performed (read or write) the registers in the internal database to be associated with the device data. -
Page 32: Hart Command Entry Formats
This value is valid only when there is a specified "Write DB Address" (see below) with a non zero byte count for write commands. The HART module will send the command if either the ProLinx-HART module OR the HART device is powered up. This is mainly used for configuration of HART devices on startup. -
Page 33: Float Db Address
ProLinx-HART ♦ ProLinx Gateway HART Protocol Configuration HART Master with Analog I/O Driver Manual 3.3.4 Float DB Address 0 to 3998 This field specifies the internal database register where the floating point values returned by the command will be placed. -
Page 34: Int. Db Address
HART Protocol Configuration ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O This parameter specifies the HART function to be executed. Any HART function can be executed, even device specific ones, but only supported commands will return formatted data and classified in floating point data and integer data. -
Page 35: Enable Db Address
ProLinx-HART ♦ ProLinx Gateway HART Protocol Configuration HART Master with Analog I/O Driver Manual 3.3.14 Enable DB Address 0 to 3999 This field specifies the internal database register to be used to enable the execution of a command. This parameter is only used if "Enable" is "4" or "5". If the value of this database register is "-1", then the command will be executed, otherwise it will not. -
Page 36: Fixed Data
HART Protocol Configuration ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O 3.3.19 Fixed Data Up to 250 HEX values separated by space This parameter is a string of HEX values to be sent with the HART command. There should be at least the number of bytes specified in the "Byte Count"... -
Page 37: Using The Commonnet Data Map
ProLinx-HART ♦ ProLinx Gateway HART Protocol Configuration HART Master with Analog I/O Driver Manual Using the CommonNet Data Map The Data Map section allows you to copy data between areas in the module's internal database. You can copy a maximum of 100 registers per Data Map command, and you can configure a maximum of 200 separate copy commands. -
Page 38: Internal Database Re-Mapping
HART Protocol Configuration ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O 3.4.1 Internal Database Re-mapping Depending on the application, you may need to copy data from one section of the module’s internal database to another section. The [Data Map] section of the CFG file allows a user to selectively copy data registers, one register up to 100 registers at a time, from one internal database to another. -
Page 39: Delay Preset
ProLinx-HART ♦ ProLinx Gateway HART Protocol Configuration HART Master with Analog I/O Driver Manual 3.4.6 Delay Preset This parameter sets an interval for each Data Map copy operation. The value you put for the Delay Preset is not a fixed amount of time. It is the number of firmware scans that must transpire between copy operations. -
Page 40: Downloading A File From Pc To The Module
HART Protocol Configuration ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O Downloading a File from PC to the Module Use a null-modem serial cable to connected the serial COM port on your PC and the Debug/Configuration serial port on the module. -
Page 41: Reference
ProLinx-HART ♦ ProLinx Gateway Reference HART Master with Analog I/O Driver Manual Reference In This Chapter HART Universal Commands ..............42 HART Common Practice Commands ............ 55 Error/Status Data ................... 85 ProLinx 5108 / 5208 HART Field Connections ........90 ProSoft Technology, Inc. -
Page 42: Hart Universal Commands
Reference ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O HART Universal Commands COMMAND 00 - Read Unique Identifier Description This command gets the long address of the HART device plus other manufacturer information like Manufacturer ID, Device Type Code, Software Revision, Hardware Revision, and so on. -
Page 43: Command 01 - Read Primary Variable
ProLinx-HART ♦ ProLinx Gateway Reference HART Master with Analog I/O Driver Manual COMMAND 01 - Read Primary Variable Description This command gets the device Primary Variable and the Primary Variable Units Write Parameters NONE Floating Point Data Returned Word High Byte... -
Page 44: Command 02 - Read Current And Percent Of Range
Reference ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O COMMAND 02 - Read Current And Percent Of Range Description This command gets the current of the loop that is forced by the HART device and the Percent of Range of the Current. -
Page 45: Command 03 - Read Dynamic Variables
ProLinx-HART ♦ ProLinx Gateway Reference HART Master with Analog I/O Driver Manual COMMAND 03 - Read Dynamic Variables Description This command gets the current and four (predefined) dynamic Variables. Write Parameters NONE Floating Point Data Returned Word High Byte Low Byte... -
Page 46: Command 06 - Write Polling Address
Reference ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O COMMAND 06 - Write Polling Address Description This command sets the polling address of a HART device. Extreme care should be taken when you use this command because you can loose the communication with the device. -
Page 47: Command 12 - Read Message
ProLinx-HART ♦ ProLinx Gateway Reference HART Master with Analog I/O Driver Manual COMMAND 12 - Read Message Description This command reads an ASCII message contained in the HART Device and written by the Write Message command 17. Write Parameters NONE... -
Page 48: Command 13 - Read Tag, Descriptor And Date
Reference ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O COMMAND 13 - Read Tag, Descriptor and Date Description This command reads an ASCII Tag which identifies the device, an ASCII descriptor of the device and the last Date it has been configured. -
Page 49: Command 14 - Read Pv Sensor Info
ProLinx-HART ♦ ProLinx Gateway Reference HART Master with Analog I/O Driver Manual COMMAND 14 - Read PV Sensor Info Description This command gets information about the Primary Variable sensor, like limits and span. Write Parameters NONE Floating Point Data Returned... -
Page 50: Command 15 - Read Output Information
Reference ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O COMMAND 15 - Read Output Information Description This command gets information about the Primary Variable Output Information. Write Parameters NONE Floating Point Data Returned Word High Byte Low Byte... -
Page 51: Command 16 - Read Final Assembly Number
ProLinx-HART ♦ ProLinx Gateway Reference HART Master with Analog I/O Driver Manual COMMAND 16 - Read Final Assembly Number Description This command reads the final assembly number of the HART device. Write Parameters NONE Floating Point Data Returned NONE Integer Data Returned... -
Page 52: Command 17 - Write Message
Reference ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O COMMAND 17 - Write Message Description This command writes an ASCII message contained in the HART Device and that can be read with command 12. Write Parameters Word... -
Page 53: Command 18 - Write Tag, Descriptor And Date
ProLinx-HART ♦ ProLinx Gateway Reference HART Master with Analog I/O Driver Manual COMMAND 18 - Write Tag, Descriptor and Date Description This command writes an ASCII Tag which identifies the device, an ASCII descriptor of the device and the last Date it has been configured. -
Page 54: Command 19 - Write Final Assembly Number
Reference ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O COMMAND 19 - Write Final Assembly Number Description This command writes the final assembly number of the HART device. Write Parameters Word High Byte Low Byte Final Assembly Number 0... -
Page 55: Hart Common Practice Commands
ProLinx-HART ♦ ProLinx Gateway Reference HART Master with Analog I/O Driver Manual HART Common Practice Commands COMMAND 33 - Read Transmitter Variables Description This command gets four user selected dynamic Variables. Write Parameters Word High Byte Low Byte Transmitter Variable Code For Slot 0... -
Page 56: Command 34 - Write Damping Value
Reference ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O COMMAND 34 - Write Damping Value Description This command writes the damping value of a HART device. Write Parameters Word High Byte Low Byte Floating Point Damping Value (Sec) -
Page 57: Command 35 - Write Range Values
ProLinx-HART ♦ ProLinx Gateway Reference HART Master with Analog I/O Driver Manual COMMAND 35 - Write Range Values Description This command writes the Upper and Lower range of the Primary Variable Write Parameters Word High Byte Low Byte Range Units Code... -
Page 58: Command 36 - Set Upper Range Value
Reference ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O COMMAND 36 - Set Upper Range Value Description This command is similar in effect to push the SPAN button of the HART device but doing it remotely through the HART network. -
Page 59: Command 37 - Set Lower Range Value
ProLinx-HART ♦ ProLinx Gateway Reference HART Master with Analog I/O Driver Manual COMMAND 37 - Set Lower Range Value Description This command is similar in effect to push the ZERO button of the HART device but doing it remotely through the HART network. -
Page 60: Command 38 - Reset Configuration Changed Flag
Reference ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O COMMAND 38 - Reset Configuration Changed Flag Description This command resets the status bit that indicates that configuration has been changed. Write Parameters NONE Floating Point Data Returned... -
Page 61: Command 39 - Eeprom Control
ProLinx-HART ♦ ProLinx Gateway Reference HART Master with Analog I/O Driver Manual COMMAND 39 - EEPROM Control Description This command operates over the EEPROM changing its settings. Write Parameters Word High Byte Low Byte EEPROM Control Code EEPROM Control Code... -
Page 62: Command 40 - Enter Exit Fixed Current Mode
Reference ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O COMMAND 40 - Enter Exit Fixed Current Mode Description This command writes the damping value of a HART device. Write Parameters Word High Byte Low Byte Floating Point Current (mA) -
Page 63: Command 41 - Perform Transmitter Self Test
ProLinx-HART ♦ ProLinx Gateway Reference HART Master with Analog I/O Driver Manual COMMAND 41 - Perform Transmitter Self Test Description This command starts the HART device Self Test to find if there is any problem with the device hardware. Write Parameters... -
Page 64: Command 42 - Perform Master Reset
Reference ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O COMMAND 42 - Perform Master Reset Description This command performs a master reset in the HART device. Write Parameters NONE Floating Point Data Returned NONE Integer Data Returned... -
Page 65: Command 43 - Set Pv Zero
ProLinx-HART ♦ ProLinx Gateway Reference HART Master with Analog I/O Driver Manual COMMAND 43 - Set PV Zero Description This command forces the Primary Value to Zero. Write Parameters NONE Floating Point Data Returned NONE Integer Data Returned Word High Byte... -
Page 66: Command 44 - Write Pv Units
Reference ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O COMMAND 44 - Write PV Units Description This command changes the setting of the Primary Variable units. Write Parameters Word High Byte Low Byte Primary Variable Units Code... -
Page 67: Command 45 - Trim Dac Zero
ProLinx-HART ♦ ProLinx Gateway Reference HART Master with Analog I/O Driver Manual COMMAND 45 - Trim DAC Zero Description This command calibrates the device Digital to analog converter zero. This is done by writing the same current value that is measured in the loop. -
Page 68: Command 46 - Trim Dac Gain
Reference ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O COMMAND 46 - Trim DAC Gain Description This command calibrates the device Digital to analog converter gain. This is done by writing the same current value that is measured in the loop. -
Page 69: Command 47 - Write Transfer Function
ProLinx-HART ♦ ProLinx Gateway Reference HART Master with Analog I/O Driver Manual COMMAND 47 - Write Transfer Function Description This command changes the setting of the Transfer Function of the HART device. Write Parameters Word High Byte Low Byte Transfer Function Code... -
Page 70: Command 48 - Read Additional Transmitter Status
Reference ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O COMMAND 48 - Read Additional Transmitter Status Description This command gets extended information about the status of the Transmitter. This information is specific for each transmitter. Write Parameters... -
Page 71: Command 49 - Write Pv Sensor Serial Number
ProLinx-HART ♦ ProLinx Gateway Reference HART Master with Analog I/O Driver Manual COMMAND 49 - Write PV Sensor Serial Number Description This command changes the sensor serial number of the Primary Variable. Write Parameters Word High Byte Low Byte Sensor Serial Number (Byte 0) -
Page 72: Command 50 - Read Dynamic Variable Assignments
Reference ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O COMMAND 50 - Read Dynamic Variable Assignments Description This command gets the actual assignment of the Dynamic Variables returned with command 3. Write Parameters NONE Floating Point Data Returned... -
Page 73: Command 51 - Write Dynamic Variable Assignments
ProLinx-HART ♦ ProLinx Gateway Reference HART Master with Analog I/O Driver Manual COMMAND 51 - Write Dynamic Variable Assignments Description This command sets the assignment of the Dynamic Variables returned with command 3. Write Parameters Word High Byte Low Byte... -
Page 74: Command 52 - Set Transmitter Variable Zero
Reference ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O COMMAND 52 - Set Transmitter Variable Zero Description This command forces a selected transmitter variable to zero. Write Parameters Word High Byte Low Byte Transmitter Variable Code Transmitter Variable Code... -
Page 75: Command 53 - Write Transmitter Variable Units
ProLinx-HART ♦ ProLinx Gateway Reference HART Master with Analog I/O Driver Manual COMMAND 53 - Write Transmitter Variable Units Description This command changes a selected transmitter variable unit. Write Parameters: Word High Byte Low Byte Transmitter Variable Code Transmitter Variable Units Code... -
Page 76: Command 54 - Read Transmitter Variable Information
Reference ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O COMMAND 54 - Read Transmitter Variable Information Description This command gets information about any selected transmitter variable sensor. Write Parameters Word High Byte Low Byte Transmitter Variable Code... -
Page 77: Command 55 - Write Transmitter Variable Damping Value
ProLinx-HART ♦ ProLinx Gateway Reference HART Master with Analog I/O Driver Manual COMMAND 55 - Write Transmitter Variable Damping Value Description This command writes the Damping Value of a user selected transmitter variable. Write Parameters Word High Byte Low Byte... -
Page 78: Command 56 - Write Transmitter Variable Sensor Serial Number
Reference ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O COMMAND 56 - Write Transmitter Variable Sensor Serial Number Description This command writes the Serial Number of a user selected transmitter variable. Write Parameters Word High Byte Low Byte... -
Page 79: Command 57 - Read Unit Tag Descriptor Date
ProLinx-HART ♦ ProLinx Gateway Reference HART Master with Analog I/O Driver Manual COMMAND 57 - Read Unit Tag Descriptor Date Description This command reads an ASCII Tag which identifies the device, an ASCII descriptor of the device and the last Date it has been configured. -
Page 80: Command 58 - Write Unit Tag Descriptor Date
Reference ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O COMMAND 58 - Write Unit Tag Descriptor Date Description This command writes an ASCII Tag which identifies the device, an ASCII descriptor of the device and the last Date it has been configured. -
Page 81: Command 59 - Write Number Of Response Preambles
ProLinx-HART ♦ ProLinx Gateway Reference HART Master with Analog I/O Driver Manual COMMAND 59 - Write Number Of Response Preambles Description This command sets the number of preambles that the HART slave will use in every command response. Write Parameters... -
Page 82: Command 108 - Write Burst Mode Command Number
Reference ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O COMMAND 108 - Write Burst Mode Command Number Description This command sets the command number that the HART device will use in Burst Mode. Write Parameters Word High Byte... -
Page 83: Command 109 - Burst Mode Control
ProLinx-HART ♦ ProLinx Gateway Reference HART Master with Analog I/O Driver Manual COMMAND 109 - Burst Mode Control Description This command sets the HART device Burst Mode. Write Parameters Word High Byte Low Byte Burst Mode Control Code Burst Mode Control Code... -
Page 84: Command 110 - Read All Dynamic Variables
Reference ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O COMMAND 110 - Read All Dynamic Variables Description This command gets all dynamic Variables. Write Parameters NONE Floating Point Data Returned Word High Byte Low Byte Primary Variable... -
Page 85: Error/Status Data
ProLinx-HART ♦ ProLinx Gateway Reference HART Master with Analog I/O Driver Manual Error/Status Data The module error/status data areas are discussed in this section. The module contains three areas related to this data. The user defines the location of these data sets in the virtual database of the module. - Page 86 Reference ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O Status Register Name Description 10701 Comm State Channel 0 communication state machine value (used for debugging) Startup Idle Transmit Pending Transmit Receive Post Transmit Idle, Waiting 10702 Device Status (bit...
-
Page 87: Module Error Codes
ProLinx-HART ♦ ProLinx Gateway Reference HART Master with Analog I/O Driver Manual HART Command List Error Data Each command in the command list for each HART channel has a word value for a status/error code. This error data list can be read using the Configuration/Debug Port and can be placed in the module’s internal database. -
Page 88: Protocol Error Codes
Reference ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O Protocol Error Codes These are error codes that are part of the HART protocol. The standard HART error codes are shown in the following tables: Error Code Word... -
Page 89: Hart Configuration Error Word
ProLinx-HART ♦ ProLinx Gateway Reference HART Master with Analog I/O Driver Manual Bit 7 of First Byte = 0 Command Error Bit 2 Analog Output Saturated Bit 1 Variable (not Primary) Out Of Limits Bit 0 Primary Variable Out of Limits... -
Page 90: Prolinx 5108 / 5208 Hart Field Connections
Reference ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O ProLinx 5108 / 5208 HART Field Connections HART field instruments are divided into four types; A through D, depending on power requirements and whether the device sinks or sources a bias or operating current from the network. -
Page 91: Wiring Diagrams
ProLinx-HART ♦ ProLinx Gateway Reference HART Master with Analog I/O Driver Manual 4.4.3 Wiring Diagrams If field instrument wiring is shielded, terminate shields at the ground terminals of the HART connector TB1. Do not terminate the shields at the instrument. - Page 92 Reference ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O Page 92 of 104 ProSoft Technology, Inc. October 13, 2011...
- Page 93 ProLinx-HART ♦ ProLinx Gateway Reference HART Master with Analog I/O Driver Manual ProSoft Technology, Inc. Page 93 of 104 October 13, 2011...
- Page 94 Reference ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O Page 94 of 104 ProSoft Technology, Inc. October 13, 2011...
-
Page 95: Support, Service & Warranty
Return Material Authorization (RMA) Policies and Conditions ....97 LIMITED WARRANTY ................99 Contacting Technical Support ProSoft Technology, Inc. (ProSoft) is committed to providing the most efficient and effective support possible. Before calling, please gather the following information to assist in expediting this process:... - Page 96 Support, Service & Warranty ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O Internet Web Site: www.prosoft-technology.com/support E-mail address: support@prosoft-technology.com Tel: +603.7724.2080, E-mail: asiapc@prosoft-technology.com Asia Pacific (location in Malaysia) Languages spoken include: Chinese, English Tel: +86.21.5187.7337 x888, E-mail: asiapc@prosoft-technology.com...
-
Page 97: Return Material Authorization (Rma) Policies And Conditions
Product or assume the risk of loss or damage in transit. Products shipped to ProSoft Technology using a shipment method other than that specified by ProSoft Technology, or shipped without an RMA number will be returned to the Customer, freight collect. Contact ProSoft Technical Support for further information. -
Page 98: Returning Units Out Of Warranty
Support, Service & Warranty ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O 5.1.3 Returning Units Out of Warranty a) Customer sends unit in for evaluation to location specified by ProSoft Technology, freight prepaid. b) If no defect is found, Customer will be charged the equivalent of $100 USD, plus freight charges, duties and taxes as applicable. -
Page 99: Limited Warranty
ProLinx-HART ♦ ProLinx Gateway Support, Service & Warranty HART Master with Analog I/O Driver Manual LIMITED WARRANTY This Limited Warranty ("Warranty") governs all sales of hardware, software, and other products (collectively, "Product") manufactured and/or offered for sale by ProSoft Technology, Incorporated (ProSoft), and all related services provided by ProSoft, including maintenance, repair, warranty exchange, and service programs (collectively, "Services"). -
Page 100: What Is Not Covered By This Warranty
Support, Service & Warranty ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O 5.2.2 What Is Not Covered By This Warranty a) ProSoft makes no representation or warranty, expressed or implied, that the operation of software purchased from ProSoft will be uninterrupted or error free or that the functions contained in the software will meet or satisfy the purchaser’s... -
Page 101: Intellectual Property Indemnity
ProLinx-HART ♦ ProLinx Gateway Support, Service & Warranty HART Master with Analog I/O Driver Manual 5.2.4 Intellectual Property Indemnity Buyer shall indemnify and hold harmless ProSoft and its employees from and against all liabilities, losses, claims, costs and expenses (including attorney’s fees and expenses) related to any claim, investigation, litigation or proceeding (whether or not ProSoft is a party) which arises or is alleged to arise from Buyer’s acts or omissions under these... -
Page 102: Limitation Of Remedies
Support, Service & Warranty ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O 5.2.6 Limitation of Remedies ** In no event will ProSoft or its Dealer be liable for any special, incidental or consequential damages based on breach of warranty, breach of contract, negligence, strict tort or any other legal theory. -
Page 103: Index
ProLinx-HART ♦ ProLinx Gateway Index HART Master with Analog I/O Driver Manual COMMAND 38 - Reset Configuration Changed Flag • 60 COMMAND 39 - EEPROM Control • 61 COMMAND 40 - Enter Exit Fixed Current Index Mode • 62 COMMAND 41 - Perform Transmitter Self Test •... - Page 104 Index ProLinx-HART ♦ ProLinx Gateway Driver Manual HART Master with Analog I/O Enabled • 29 ProLinx 5108 / 5208 HART Field Error/Status Data • 85 Connections • 90 ProLinx Gateways with Ethernet Ports • 3 ProLinx® Products Warnings • 3 ProSoft Technology®...
