Functional Specifications - HART Analog

The HART Analog Protocol exists in 4 and 8 channel implementations. This driver can be
configured on an individual channel basis to operate as a HART Master Station and
supports all the available HART commands including Universal, Common Practice and
Device Specific Commands. Each HART channel is independently configured to interface
with the internal database in the module.
The auto-poll mode allows the module to automatically collect data from each HART
instrument on the channel and store the data in the module's database without the use of
user commands. The module automatically generates HART commands 0, 3, 13, 14 and
15.
General Parameters
Internal Database
Communication parameters
Configurable Parameters per Channel Auto-Poll Enable
HART Driver
Command List
Status Data
Polling of command list
Isolated HART Analog Input Specifications
Input Range
Resolution
Input Filter
Current Input Resistance
Open circuit detection time
Over current
Common Mode Noise Rejection
Calibrated Accuracy @ 25° C
Input Isolation Voltage
24V DC Isolation Voltage
®
HART is a registered trademark of the HART Communication Foundation
ProSoft Technology, Inc.
October 13, 2011
4000 registers (words) available
Number of HART Preambles: 2 to 50
Enable Handheld: Y or N
Primary Master: Y or N
Short / Long Address Retries
Retries After Error
Poll Time After Error
Number of Commands
Slave List Error Pointer
Up to 100 command per channel, each fully configurable
for function, slave address, register to/from addressing and
word count for Floating Point or Integer Data
Error codes returned by the HART protocol available on an
individual command basis. In addition, a slave status list is
maintained per active channel.
User configurable polling of commands, including disabled,
continuous, on change of data (write only) and dynamically
user or automatic enabled.
Current: 4 to 20mA with HART
16bits
First Order Sync: 10 Hz
247.6 ohms +/- 1%
1/2 second maximum
+/-40mA continuous, maximum
105dB
4 to 20 mA: 0.05% of reading
2500 V RMS per UL 1577, transformer isolated
1500 VDC
