7.1.2 Sending SMS Text Messages to the ICX35-HWC

Using the Modbus Function Codes 6 and 16, a Modbus TCP/IP Client can send
SMS text message contents to the ICX35-HWC. In turn, the ICX35-HWC sends
the SMS text message to the phone number recipient(s).
Before triggering, you must first load the SMS text message contents, message
length, and phone number information. Below is a table of the Modbus addresses
used to send an SMS text message.
Parameter
SMS.TX_Send
SMS.TX_MessageLength
SMS.TX_NumCount
SMS.TX_MessageString
SMS.TX_Ph_Number1
SMS.TX_Ph_Number2
SMS.TX_Ph_Number3
SMS.TX_Ph_Number4
SMS.TX_Ph_Number5
1 SMS text message contents (40006): The ICX35-HWC can send up to
160 characters (80 16-bit integers) per SMS text message. To load the
text message string, use the Modbus Function Code 16 to write to
Modbus address starting at 40006 in the ICX35-HWC.
2 SMS text message length (40004): Use the Modbus Function Code 6 to
write the number of characters (up to 160) to send.
3 Amount of phone numbers to send to (40005): Use the Modbus
Function Code 6 to write the amount of phone numbers that will be used.
4 Phone number entry (40086): Use the Modbus Function Code 16 to
write the recipient's phone number including prefixes, country, code, etc.
You can enter up to 5 phone numbers, each starting at a different
Modbus address (see table above).
5 Trigger the SMS text message (40003): When you are ready to send
the SMS text message, use the Modbus Function Code 6 to write a value
of '1' to 40003.
ProSoft Technology, Inc.
October 26, 2018
Modbus Address Data Type
40003 SINT
40004 INT
40005 INT
40006 to 40085 SINT[160]
40086 to 40097 SINT[24]
40098 to 40109 SINT[24]
40110 to 40121 SINT[24]
40122 to 40133 SINT[24]
40134 to 40145 SINT[24]
Modbus TCP/IP Communications
Description
Trigger to send SMS text message when Value = 1
Number of bytes (characters) to send
Number of phone numbers that the SMS will be
sent to
SMS text message string to be transmitted
Phone number including prefixes, country, code, etc.
Phone number including prefixes, country, code, etc.
Phone number including prefixes, country, code, etc.
Phone number including prefixes, country, code, etc.
Phone number including prefixes, country, code, etc.
