Hardware Installation
User Manual
Ethernet Port LEDs
LED
100 Mbit
LNK/ACT
WWAN LED
LED
Off
Solid Green
Slow Blink
Faster Blink
Note: The WWAN LED indicates a physical connection state between the ICX35-HWC and the cell
tower. It is not an indicator of a logical connection state. There may be a situation when you may
see a "Disconnect, will retry" indicator on the ICX35-HWC webpage, even when the WWAN LED
light is on (solid green). This indicates that the module was able to make a physical connection to
the tower, but the logical connection was not made between the ICX35-HWC and the cellular
provider.
Page 90 of 137
State Description
Off No activity on the port
Flashing Amber The Ethernet port is actively transmitting or receiving data.
Off No physical connection is detected. No Ethernet communication
is possible. Check wiring and cables.
Solid Green Physical network connection detected. This LED must be ON
(solid) for Ethernet communication to be possible.
State Description
Off ICX35-HWC is powered off
On ICX35-HWC is powered and connected, but is not transmitting
or receiving.
Flashes at a steady, slow ICX35-HWC is powered and searching for a connection.
rate: 0.2 Hz (5 sec)
Flashes at a steady, fast ICX35-HWC is transmitting or receiving data.
rate: About 3 Hz (333 ms)
