Led Indicators - ProSoft Technology ICX35-HWC User Manual

ICX35-HWC ♦ Industrial Cellular Gateway
3G/4G LTE
5.3

LED Indicators

LED
PWR
ERR
MS* (Module Status)
NS* (Network Status)
* The MS and NS LED's are only enabled if the Ethernet/IP parameter is enabled in the Configuration tab of the
webpage.
Serial Port LEDs
LED
SER
TX
RX
ProSoft Technology, Inc.
October 26, 2018
State Description
Off Power is not connected to the power terminals or source is
insufficient to properly power the device.
Solid Green Power is connected to the power terminals
Off Normal operation
Solid Red A critical error has occurred. Program executable has failed or
has been user-terminated and is no longer running. Press the
Reset button or cycle power to clear the error.
Off ICX35-HWC is powered off
Solid Green Initialization complete / OK
Blinking Green ICX35-HWC is in the process of configuring
Solid Red Unrecoverable error
Blinking Red Reading config / minor error / No SIM
Off ICX35-HWC is powered off
Solid Green ICX35-HWC has a connection to cellular tower
Blinking Green ICX35-HWC is attempting to connect to cellular tower
Solid Red Duplicate IP (EtherNet/IP) / Non-recoverable network fault
Blinking Red Established connection timeout (EtherNet/IP) / Minor network
fault
State Description
Flashing Indicates that data is moving from the serial port to the WAN
port
Off No activity on the port
Flashing Amber Port is actively transmitting data
Off No activity on the port
Flashing Green Port is actively receiving data
Hardware Installation
User Manual
Page 89 of 137
