ICX35-HWC ♦ Industrial Cellular Gateway
3G/4G LTE
7 In the ICX35-HWC configuration webpage, click A
automatically redirects to the new IP address if the IP address is changed.
8 Reset your PC back to its original IP address. This IP address should be on
the same subnet as the ICX35-HWC.
9 Close your browser and open a new session. Enter the new IP address of the
ICX35-HWC to access the configuration web page. Add :8080 to specify the
correct port (192.168.0.250:8080).
2.3

Connecting to Your Cellular Provider

The ICX35-HWC supports 3G GSM/GPRS and 4G LTE (where applicable)
networks. It uses your cellular provider as an ISP (Internet Service Provider) to
connect to the Internet. All cellular service connections require a Subscriber
Identity Module (SIM) to be installed in the ICX35-HWC. This includes
connections to CDMA based services like Verizon (previously did not require a
SIM). Contact your service provider to obtain a SIM.

2.3.1 Connection Using GSM/GPRS

The Subscriber Identity Module (SIM) in the ICX35-HWC is a smartcard that
securely stores the key identifying a cellular subscriber. Generally, you will only
need to install a SIM once in the life of the cellular gateway - and it may be pre-
installed by your ProSoft Technology Representative.
Important: Your cellular provider must provide the Public APN and IP address of the SIM card.
AT&T Users: For SMS texting functionality, you must power up the ICX35-HWC with the SIM
installed within 72 hours after AT&T activates the SIM card.
ProSoft Technology, Inc.
October 26, 2018
Connecting to the ICX35-HWC
. The page
PPLY
