Modbus TCP/IP Communications

7.1.1 ICX35-HWC Diagnostic Data Retrieval

The following table displays the read-only Modbus addresses of the ICX35-HWC
diagnostics information. Use Modbus Function Code 4 to read these values.
ICX35_
Diag.RSSI
Diag.Min_RSSI *
Diag.Max_RSSI *
Diag.Cell_Net_State
Diag.MAC_Address
Diag.WAN_IP
Diag.Cell_Net_Disconnects *
Diag.LAN_KBytes_Sent *
Diag.LAN_KBytes_Received *
Diag.WAN_KBytes_Sent *
Diag.WAN_KBytes_Received *
Diag.SMS_MSGs_Sent *
Diag.SMS_MSGs_Received *
Diag.SMS_MSGs_Free *
Diag.Power_Year
Diag.Power_Month
Diag.Power_Day
Diag.Power_Hour
Diag.Power_Min
Diag.Power_Sec
Diag.Link_Days
Diag.Link_Hours
Diag.Link_Min
Diag.Link_Sec
Diag.Data_Usage_Current_Month
ProSoft Technology, Inc.
October 26, 2018
Modbus Address Data Type
SINT
30001
SINT
30002
SINT
30003
30004 SINT
30005 to 30010 SINT[6]
30011 to 30014 SINT[4]
30015 to 30016 DINT
30017 to 30018 DINT
30019 to 30020 DINT
30021 to 30022 DINT
30023 to 30024 DINT
30025 to 30026 DINT
30027 to 30028 DINT
30029 to 30030 DINT
30031 INT
30032 INT
30033 INT
30034 INT
30035 INT
30036 INT
30037 to 30038 DINT
30039 to 30040 DINT
30041 INT
30042 INT
30043 to 30044 DINT
Modbus TCP/IP Communications
Description
Current Signal Strength. Range -50 to -125 dBm
Value 1 = -128
Minimum Signal Strength. Range -50 to -125 dBm
Value = 127 (Set during initialization)
1
Maximum Signal Strength. Range -50 to -125 dBm
Value 1 = -128 (Set during initialization)
Status of the connection to the cellular network.
0: Disconnect
1: Connecting
2: Connected
Value 1 = 0 (Not connected)
ICX35-HWC MAC ID. Value 1 = Not available
Cellular network IP. Value 1 = 0.0.0.0
Number of times ICX35-HWC is disconnected from
the cellular network since power on
Number Kbytes sent on LAN since power on
Number of Kbytes received LAN since power on
Number of bytes sent WAN since power on
Number of bytes received WAN since power on
Number of SMS messages sent since power on
Number of SMS messages received since power on
Number of free slots in the Rx SMS buffer. Max 500
message storage.
Power on time year
Power on time month
Power on time day
Power on time hour
Power on time minute
Power on time seconds
Link Time: Days of cellular connection. Value
Link Time: Hours of cellular connection. Value
Link Time: Minutes of cellular connection. Value
Link Time: Seconds of cellular connection.
Value = 0
1
Data usage of current month in KB
User Manual
1 = 0
1 = 0
= 0
1
Page 111 of 137
