3. Loosen the Height Locking Handle for the Centerline Sensor
Mounting Bracket and using the Sensor Bracket Height Crank,
raise the bracket all the way.
4. Center a properly filled production container in the inspection
tunnel so that when the inspection head is lowered, it is
aligned with inspection beam.
5. Lower the inspection head until the inspection beam height is
in the proper position for either underfill or overfill detection:
• If you will perform underfill detection, align the top of the
x-ray beam slot with the fill level of the contents in the
container.
• If you will perform overfill detection, align the bottom of
the x-ray beam slot with the fill level of the contents in the
container.
6. Tighten the inspection head height locking handle to secure the
head positioning.
7. If you are not in the Calibrate Mode, Press Key 5 until you
reach SYSTEM DISPLAY and then press the Arrow Key to
select CALIBRATE.
8. Press Key 1 until you reach TARGET HEAD HEIGHT.
9. Read the value displayed in the Head Height Counter. The
counter is located in the upper left corner on the front of the
FT-70 (see illustration 4-2).
10. Use the Arrow Key to enter the value in the TARGET HEAD
HEIGHT function.
11. Press Key 5 until you reach SYSTEM DISPLAY and then press
the Arrow Key to select OPERATE.
12. If you will not be performing further alignment procedures,
turn on the Safety Interlock Switch to reactivte the X-ray
Generator. See Chapter 5: The Safety Interlock Switch.
