Led Logic - Filtec FT-70c Service And Technical Reference Manual

LED Configurations
Section 1, S27= close
LED
Bank 1, S28= close
1 Diag Error
2 Reject Pulse
3 Hi Res Encoder
4 Low Foam
5 Downcan/Smash
6 Bulged/High Cap
7 Missing Cap/Lid
8 Trigger

LED Logic

Industrial Dynamics Company, Ltd. © Form 40256-0600
Chapter 10: Controller Board Dip Switches and LEDs
The LED assignments below are listed by the Section and Bank.
Selecting a Section and Bank is controlled by Dip Switches S2- 7
and S2-8. The multiple banks are necessary to handle the various
options available for the FT-70.
Section 1, S27= close
Bank 2, S28= open
Label 1
Label 2
Label 3
Label 4
Label 5
Label 6
Label 7
Label 8
The standard detection logic for the LEDs is on when the sensor is
blocked and off when a sensor is clear. Some options, such as High
Cap Detection, use reverse detection logic. When reverse detection
logic is used the LED is off when the sensor is blocked and on
when the sensor is clear.
Refer to the System Configuration Sheet located inside the cover of
your FT-70 for you specific configuration.
Section 2, S27= open
Bank 1, S28= close
Remote Clr
Broken Slat or Batch Rej
Low Res Encoder
X-ray Enable or Optical FL
X-ray Failure
Extrn or FSR 1
Slat Backup or Reject Verify
Trigger
Section 2, S27= open
Bank 2, S28= open
Inlabeler 1
Inlabeler 2
Inlabeler 3
Inlabeler 4
Inlabeler 5
Cntr Present
System Timing
Trigger
10-9
