Industrial Dynamics Company, Ltd. © Form 40256-0600
17. Examine the marking in the grease. If your calibration
procedure was accurate, the mark will be close to the center of
the pad. If the mark is off, adjust the Millimeter Translation
Value as follows:
• If the rejector fired late (the mark is in the downstream
third of the rejector pad), decrease the millimeter trans-
lation value by 2.
• If the rejector fired early (the mark is in the upstream third
of the rejector pad), increase the millimeter translation
value by 2.
18. Repeat steps 16 and 17 until the rejector is contacting the cans
directly on the centerline of the pad.
19. To store the settings in system memory, close dip switch S1-2
and then press Key 5 until SAVE DEFAULT CONSTANTS
appears.
20. Press the Arrow Key to execute. When COMPLETED appears,
open S1-2 to protect the saved settings.
21. Press Key 5 until SYSTEM DISPLAY appears and press the
Arrow Key to select the Operate Mode. This returns the FT-70
to a secured operating mode and completes the calibration
procedure.
22. If you are using this production line to produce more than one
type of container, you must repeat this procedure for each
different container type (i.e. containers with different
diameters, or line speeds).
Chapter 6: Calibration Procedures
6-27
