FT-70 Fill Level Inspector Service Manual
Configure the Missing Lid Function
Configure the Bulged End Function
4-22
1. If your FT-70 is not in the Calibrate Mode, Press Key 5 until you
reach SYSTEM DISPLAY and then press the Arrow Key to
enter the Calibrate Mode.
2. Open dip switch S1-5.
3. Press Key 5 until MISSING LID appears and use the Arrow
Key to select the type of missing lid sensor installed.
4. Close dip switch S1-5.
5. Press Key 2 until MISSING LID STATUS appears and then
press the Arrow Key to activate the function.
6. If you are finished configuring the FT-70, press Key 5 until you
reach SYSTEM DISPLAY and then press the Arrow Key to
return to the Operate Mode.
7. Calibrate the Missing Lid Sensor according to the instructions
in Chapter 6, Calibrating the Missing Lid Sensor.
1. If your FT-70 is not in the Calibrate Mode, Press Key 5 until you
reach SYSTEM DISPLAY and then press the Arrow Key to
enter the Calibrate Mode.
2. Open dip switch S1-5.
3. Press Key 5 until BULGED END appears and use the Arrow
Key to select PRESENT.
4. Close dip switch S1-5.
5. Press Key 2 until BULGED END STATUS appears and then
press the Arrow Key to activate the function.
6. If you are finished configuring the FT-70, press Key 5 until you
reach SYSTEM DISPLAY and then press the Arrow Key to
return to the Operate Mode.
7. Calibrate the Bulged End Sensor according to the instructions
in Chapter 6, Calibrating the Bulged End Sensor.
Industrial Dynamics Company, Ltd. © 40256-0600
