The TLS 525M, TLS 725M, and TLS 1025M have the same physical appearance as the
corresponding TLP Pro models but have different firmware. The TLS models can only be used
with the room scheduling software (see the Room Agent Help File and Room Agent User Guide,
which are available at

Features

All Models

•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•

TLP Pro 525M, TLP Pro 725M, and TLP Pro 1025M

•
www.extron.com
LCD touchscreen — with 24-bit color depth and a vibrant edge-to-edge glass display
TLP Pro 525 Series — 5-inch touchscreen with 800x480 (WVGA) resolution
•
TLP Pro 725 Series — 7-inch touchscreen with 1024x600 (WSVGA) resolution
•
TLP Pro 1025 Series — 10.1-inch touchscreen with 1280x800 (WXGA) resolution
•
Gorilla Glass screen is tough, scratch, and smudge-resistant — Corning
®
Glass is stronger and more scratch-resistant than standard glass, while maintaining touch
sensitivity, color saturation, and brightness.
Faster, quad-core processing — provides enhanced response and overall user
experience.
Power over Ethernet (PoE 802.3af, class 3) compliance — allows the touchpanel to
receive power and communication over a single Ethernet cable, eliminating the need for a
(power injector sold separately).
local power supply
Optional Mounting Kits available
Mounting options for TLP Pro 525M, TLP Pro 725M, and TLP Pro 1025M series:
•
Mount in a one-gang (TLP Pro 525M Series) or two-gang (TLP Pro 725M and
•
TLP Pro 1025M Series) junction box or on a wall, lectern, or any flat surface,
including glass, with the optional mounting kits (see www.extron.com).
Mounting options for TLP Pro 525T Series, TLP Pro 725T Series, and
•
TLP Pro 1025T series:
Sit on a tabletop — fixed 65° viewing angle
•
Threaded holes in baseplate allow for secure mounting to a table
•
Can be used with the optional SMA-2 Swivel Mount Adapter
•
Compatible with the full range of Extron IPL Pro and IPCP Pro control processors
— allows easy integration into existing systems.
Built-in speaker — provides audible feedback from button presses.
Light sensor — adjusts screen brightness as the ambient room lighting changes.
Configurable red and green status lights — indicate the availability or call status of a
room.
System connection status indicator — the communication LED provides visual feedback
if the touchpanel is not communicating with a control processor.
Automatic clock synchronization — allows the touchpanel to display the accurate time
and date.
Energy-saving features —
Adjustable sleep timer puts the touchpanel into sleep mode.
•
Motion detector wakes the touchpanel.
•
Manage, monitor, and control this device remotely — using GlobalViewer Enterprise
(GVE) Resource Management software.
Fully customizable using Extron control system software — GUI Designer combined
with Global Configurator Plus, Global Configurator Professional, or Global Scripter.
Supports the Extron Control App and Extron Control for Web.
High speed USB 2.0 port — for future expansion
Digital input — allows connections to a variety of devices, such as sensors and switches.
TLP Pro 525, 725, and 1025 Series Touchpanels • Introduction
).
