Display

1
Press the button in the navigation panel at the top of the screen to open the
Display
screen.
Display
Status Network
Sleep Timer
2
3
4
Minutes
On Off
Figure 10.
Display Screen
The Display screen allows you to set the
, and
LCD Brightness Wake on Motion
Sleep Timer — Determines how long the panel is inactive before it enters sleep mode,
•
when the screen goes dark to save power. Toggle between
, use the arrows to adjust the value between
On
Auto Brightness — Provides a suitable amount of backlighting that is automatically
•
calculated from the amount of ambient light detected by the light sensor (see
on page 6).
LCD Brightness — Allows you to adjust the screen brightness, using the slider control.
•
Wake on Motion — Activates the panel from Sleep mode when motion is detected near
•
the unit. Toggle between
TLP Pro 525, 725, and 1025 Series Touchpanels • On-screen Menus
Audio Advanced
Auto Brightness
On Off
LCD Brightness
0 50
Wake on Motion
On Off
Sleep Timer ,
.
and
1
and .
On Off
Display
Exit
100
Auto Brightness ,
and . If the sleep timer is
On Off
minutes.
120
figure 2, D ,
