Menu PIN
The PIN setup options allow you to enable, disable, or change the setup menu PIN. The PIN is a
4-digit number. Each digit can have any value from 0-9.
1.
Select the first digit of the PIN. When selected, it is highlighted in yellow.
Enter New Menu PIN
1 2 3
1 2 3
4 5 6
7 8 9
0
Figure 14.
Numeric Keypad for Setting PIN
2. Press a number on the keypad. That number appears in the PIN.
3. Repeat steps 1 and 2 for the other 3 digits.
4. The title bar changes to
5. Enter the PIN a second time. When the PIN entered on the second occasion matches the
PIN entered on the first occasion, the PIN is set and the dialog closes.
Communication LED
The LED can be switched on or off by pressing the
Rear Status Lights
These lights can be switched on or off by pressing the
(TLP Pro 725M and TLP Pro 1025M series only).
TLP Pro 525, 725, and 1025 Series Touchpanels • On-screen Menus
4
Back
Cancel
.
Confirm New Menu Pin
Enable
Enable
or button.
Disable
or button
Disable
