17.4.5

Analog Sensor Calibration Data

Name
Primary analogue sensor
P3205 U16
max left position
Primary analogue sensor
P3207 U16
max right position
Primary analogue sensor
P3209 U16
neutral position
Redundant analogue sensor
P3211 U16
max left position
Redundant analogue sensor
P3213 U16
max right position
Redundant analogue sensor
P3215 U16
neutral position
5V sensor supply for
primary analogue sensor P3217 U16
during calibration
5V sensor supply for
redundant analogue sensor P3219 U16
during calibration
Automatically adjusted
cylinder stroke volume P3221 U16
(analogue WAS)
Automatically adjusted
maximum steer angle to P3223 U16
left side (analogue WAS)
Automatically adjusted
maximum steer angle to P3225 U16
right side (analogue WAS)
Important
For analog sensor calibration data sector, the following rules apply:
P3205 < P3207 < P3209 OR P3205 > P3207 > P3209
AND if P3245 is set to 255 (redundant WAS is present)
P3211 < P3213 < P3215 OR P3211 > P3213 > P3215
152 | © Danfoss | August 2018
Description of parameter
mVolts Primary analogue sensor voltage output for leftmost position
mVolts Primary analogue sensor voltage output for rightmost position
mVolts Primary analogue sensor voltage output for neutral position
mVolts Redundant analogue sensor voltage output for leftmost position
mVolts Redundant analogue sensor voltage output for rightmost position
mVolts Redundant analogue sensor voltage output for neutral position
mVolts Measured Supply voltage during calibration of the primary analogue sensor
Measured Supply voltage during calibration of the redundant analogue
mVolts
sensor
Automatically adjusted cylinder stroke volume, for using analogue WAS,
ccm
found during WAS auto-calibration
Automatically adjusted maximum steer angle to left side, for using
Deg
analogue WAS, found during WAS auto-calibration
Automatically adjusted maximum steer angle to right side, for using
Deg
analogue WAS, found during WAS auto-calibration
Table 68
Range
OEM, Dealer 0 6000
OEM, Dealer 0 6000
OEM, Dealer 0 6000
OEM, Dealer 0 6000
OEM, Dealer 0 6000
OEM, Dealer 0 6000
OEM, Dealer 4650 5350
OEM, Dealer 4650 5350
OEM, Dealer 100 65535
OEM, Dealer 0 65535
OEM, Dealer 0 65535
AQ00000211
500
4500
2500
500
4500
2500
5000
5000
65535
65535
65535
