Carrier Removal And Insertion - Oracle SPARC Enterprise M4000 Installation And Service Manual

FIGURE 1-13
3
4
Figure Legend
1 Carrier main body (metal)
2 Carrier plate (plastic)
3 Carrier slot keyholes
1.3.1

Carrier Removal and Insertion

A carrier operates by raising or lowering a PCI card into or out of a card socket. The
vertical movement is approximately 0.4 in./10 mm.
A small metal latch (item 3 in
latch locks the carrier handle in the extended position. This action prevents the
carrier plate and PCI card from falling and damaging the PCI slot connector as you
pull the carrier unit out of the carrier slot.
1-18 External I/O Expansion Unit for SPARC Enterprise Mx000 Servers Installation and Service Manual • April 2011
Carrier Features
1
2
4
5
6
FIGURE 1-14
5
Carrier handle
Section 1.3.2, "Card Locks" on page
Card locks (see
Turnaround area for card lock
) is located at the front of the carrier. The
6
5
1-20)
5
