TABLE C-1
more information about IOU slot names, refer to the discussions of I/O device
mapping in the SPARC Enterprise M4000/M5000/M8000/M9000 Servers Administration
Guide.
TABLE C-1
IOU Slot
IOU Slot 0
IOU Slot 1
IOU Slot 2
IOU Slot 3
IOU Slot 4
* Slot 0 is a PCI-X slot. The External I/O Expansion Unit link card cannot be used in this slot.
TABLE C-2
more information about IOU slot names, refer to the discussions of I/O device
mapping in the SPARC Enterprise M4000/M5000/M8000/M9000 Servers Administration
Guide.
TABLE C-2
IOU Slot
IOU Slot 0
IOU Slot 1
IOU Slot 2
IOU Slot 3
IOU Slot 4
IOU Slot 5
IOU Slot 6
IOU Slot 7
The OpenBoot PROM maps several types of connecting devices inside the I/O boats
in the External I/O Expansion Unit. These connecting devices generally have
multiple I/O ports which appear in the OpenBoot PROM report as pci@0, pci@1,
pci@0,1, and so forth. These connecting devices are switching circuits which switch
between multiple inputs, and bridge circuits, which connect PCI-X buses to PCI
Express buses.
C-2 External I/O Expansion Unit for SPARC Enterprise Mx000 Servers Installation and Service Manual • April 2011
lists the IOU slots in the SPARC Enterprise M4000/M5000 servers. For
IOU Slots in SPARC Enterprise M4000/M5000 Servers
OpenBoot PROM Device Path Name
*
/pci@x0,600000/pci@0/pci@8/pci@0,1
/pci@x0,600000/pci@0/pci@9
/pci@x1,700000
/pci@x2,600000
/pci@x3,700000
lists the IOU slots in the SPARC Enterprise M8000/M9000 servers. For
IOU Slots in SPARC Enterprise M8000/M9000 Servers
OpenBoot PROM Device Path Name
x
pci@ 0,600000
x
pci@ 1,700000
x
pci@
2,600000
x
pci@ 3,700000
x
pci@ 4,600000
x
pci@ 5,700000
x
pci@ 6,600000
x
pci@ 7,700000
