4.2

Identifying Firmware Versions

It might be helpful to identify firmware versions in the External I/O Expansion Unit
when troubleshooting problems. Firmware is located on the motherboard and on
each link card.
To identify versions of firmware, use the ioxadm -v list command. In the output,
firmware versions are listed in the column marked "FW Ver".
XSCF> ioxadm -v list
Location
IOX@X04E
IOX@X04E/PS0
IOX@X04E/PS1
IOX@X04E/IOB0
IOX@X04E/IOB0/LINK
IOU#0-PCI#3
IOX@X04E/IOB1
IOX@X04E/IOB1/LINK
IOU#0-PCI#1
XSCF>
This example shows five instances of firmware in an External I/O Expansion Unit
that is configured with two I/O boats:
IOX in the Type column identifies the chassis, where the fan controller firmware is
■
located.
OP in the Type column identifies the link cards, where the bridge controller
■
firmware is located. A link consists of two link cards, and there are two links in
this example (one link for each I/O boat), for a total of four link cards:
■
■
Refer to the ioxadm(8) man page for more information.
Type FW Ver
IOX 2.4
A195 -
A195 -
PCIX -
OP 2.4
OP 2.4
PCIE -
OP 2.4
OP 2.4
LINK in the Location column identifies a link card in an I/O boat.
IOU#n-PCI#n in the Location column identifies a link card in a server.
Serial Num Part Num
XCX04E 5016937-03
T01180 3001701-03
T01097 3001701-03
XX00EL CF005016938/5016938-05
XF01D3 CF005017040/5017040-03
XF014C 5017040-03
XE00C1 CF005016939/5016939-04
XF00W2 5017040-03
XF01AX CF005017040/5017040-03
Chapter 4 Servicing and Replacing Components
State
On
On
On
On
On
On
On
On
On
4-3
