AC Cables and Cords for Type B Cable Management Plate
FIGURE 2-12
1
2
Figure Legend
1
Internal AC cable, left
2
AC cord (connectors are placed in rectangular opening to reduce height)
3
Internal AC cable, right
3
Chapter 2
Installing the External I/O Expansion Unit in a Rack
2-15
