ORDERING INFORMATION

BILL OF MATERIALS

Table 9.
Qty Reference Designator
1 C1
5 C11, C13, C15, C28, C53
13 C12, C19, C49, C50, C61 to
C69
2 C16, C54
3 C2, C7, C48
6 C20 to C22, C40, C42, C44
1 C3
1 C30
1 C35
2 C36, C37
1 C38
20 C4, C5, C14, C17, C18, C23
to C27, C31, C32, C39, C41,
C43, C45, C47, C52, C55, C57
1 C46
1 C51
1 C58
2 C59, C60
2 C6, C56
4 C8, C29, C33, C34
2 C9, C10
1 D1
1 D2
1 D3
2 D4, D10
2 D5, D7
1 D6
2 D8, D9
1 F2
5 FER1 to FER3, FER5, FER6
1 FER4
1 GP1
2 J1, J2
1 J3
3 J4 to J6
1 J7
1 J8
1 J9
1 JP10
2 JP11, JP15
2 JP12, JP14
2 JP16, JP17
12 JP1 to JP9, JP13, JP18, JP19
1 L1
1 LED1
1 LED2
4 LED3 to LED5, LED7
1 LED6
User Guide
Description
20 pF, 16 V, ±5%, 0402, C0G
0.01 μF, 16 V, 10%, 0402, X7R
0.1 μF, 35 V, 10%, 0402, X7R
4.7 μF, 6.3 V, 20%, 0603, X5R
20 pF, 16 V, ±5%, 0402, C0G
5600 pF, 25 V, X7R, 10%, 0402
0.47 μF, 16 V, 10%, 0402, JB
4.7 μF, 10 V, 10%, 0603, X6S
1 μF, 16 V, 10%, 0603, X5R
1000 pF, 50 V, 5%, 1206
10 μF, 16 V, 10%, 1210, X5R
0.1 μF, 10 V, 10%, 0402, X5R
0.1 μF, 16 V, 10%, 0402, X7R
1 μF, 50 V, 10%, 0603, X5S
2.2 μF, 10 V, 10%, 0805, X5R
18 pF, 50 V, 5%, 0402, NP0
1 μF, 6.3 V, 20%, 0402, X5R
10 μF, 6.3 V, 20%, 0603, X5R
8 pF, 16 V, ±0.5 pF, 0402, C0G
Buzzer, 75 dB, 3 V, 4 kHz
200 mA, BAS40DW, SOT-363
30 A, GSOT05, SOT23-3
15 kV, ESDA5V3SC6, SOT95P280X145-6N
15 kV, ESD7004, DFN50P250X100-10N
5 A, MBRS540T3G, SMC
1 A, RS1B, SMB
3 A, resettable FUS004
600 Ω at 100 MHz, 500 mA, 1206
190 Ω at 100 MHz, 5 A FER002
Test loop, LOOP_2838
SMC, threaded, AMPHENOL_152119
0.1'' , 8-pin, HARWIN_M20-7880446
IDC, 8 × 1
IDC, 10 × 1, SAMTEC_SSW-110-01-T-S
Battery holder 20 mm, BATT_BS-3
Battery holder, AA BATT_2460
IDC, 4 × 2
IDC, 2 × 2
IDC, 3 × 2
IDC, 3 × 1
IDC, 2 × 1
2.2 μH, 20%, PKG
Red LED, LED_0603
Green LED, LED_0603
Yellow LED, LED_0603
RGB LED_SM1210RGB
