Qty Reference Designator
2 P1, P2
1 P1A
1 P3
2 P4, P12
3 P5, P9, P10
2 P6, P11
1 P7
1 P8
59 R1, R2, R4, R7, R11, R12,
R14, R15, R17, R31 to R37,
R43, R46, R48 to R51, R54,
R56, R57, R69, R70, R71,
R74, R75, R78 to R84, R86 to
R102, R108, R121, R123,
R125, R129, R136
1 R101
1 R105
2 R110, R111
1 R113
4 R116, R117, R137, R138
2 R13, R124
1 R16
3 R19 to R21
6 R23, R61 to R64, R114
2 R24, R25
8 R3, R41, R42, R126, R127,
R133 to R135
2 R45, R85
3 R47, R103, R104
4 R5, R58, R122, R128
8 R52, R59, R60, R109, R112,
R118 to R120
3 R53, R65, R66
18 R6, R26 to R30, R39, R40,
R67, R68, R72, R73, R76,
R107, R115, R130 to R132
2 R8, R18
9 R9, R10, R22, R38, R44, R55,
R77, R106, R140
1 R139
1 R144
5 SW1 to SW5
1 U1
1 U13
2 U14, U16
1 U2
1 U3
1 U4
1 U5
1 U6
1 U7
1 U8
4 U9 to U12
Description
0.05'' , 5 × 2, SAMTEC_TFM-105-02-S-DA
0.6 mm, 120-pin HIROSE_FX8-120PSV1(91)
0.05, ' ' 10 × 2, SAMTEC_TFM-110-02-S-DA
IDC, 10 × 2, TE_5103308-5
0.05'' , 10-pin, SAMTEC_SHF-105-01-L-DTH
USB, 5-pin, CON069
IDC, 4 × 1
DC power jack, 0.65 mm, CON045
0 Ω, 1/10 W, 5%, 0402
10 MΩ, 1/10 W, 5%, 0603
316.0 kΩ, 1/16 W, 1%, 0402
4.7 kΩ, 1/16 W, 5%, 0402
1 MΩ, 1/10 W, 5%, 0603
33 Ω, 1/16 W, 5%, 0402
0 Ω, 1/8 W, 5%, 0805
0 Ω, 1/8 W, 5%, 0805
0.051 Ω, 1/2 W, 1%, 1206
499.0 Ω, 1/10 W, 1%, 0402
2.2 kΩ, 1/10 W, 5%, 0402
100 kΩ, 1/16 W, 5%, 0402
1 MΩ, 1/10 W, 5%, 0603
169.0 Ω, 1/10 W, 1%, 0402
10 kΩ, 1/16 W, 5%, 0402
10 kΩ, 1/16 W, 5%, 0402
49.9 Ω, 1/16 W, 1%, 0402
100 kΩ, 1/16 W, 5%, 0402
5 MΩ, 1/20 W, 5%, 0402
0 Ω, 1/10 W, 5%, 0402
3 3Ω, 1/16 W, 5%, 0402
33 Ω, 1/16 W, 5%, 0402
Momentary SW_ADTSMW64
ADuCM4050 LFCSP64
ADM6315-29D3 SOT143
SN74LVC1G08 SOT23-5
ADXL363BCCZ LFCSP16
ADR127BUJZ SOT95P280X100-6N
FT232RQ QFN32
ADR441ARMZ MSOP8
ADT7420UCPZ LFCSP16
W25Q32 SO8W
MK20DX128VFM5
SN74LVC1G125 SOT23-5
Rev. 0 | Page 30 of 31
ADZS-U4050LF-EZKIT
Manufacturer
Samtec
Hirose Electric Group
Samtec
Mouser
Samtec
Hirose Electric Co Ltd
FCI
CUI Inc.
Panasonic
Vishay
Vishay
Vishay
Vishay
Vishay
Vishay
Vishay
SEI
Panasonic
Panasonic
Vishay
Panasonic
Panasonic
Vishay
Vishay
SEI
Vishay
Ohmite
Panasonic
Panasonic
Vishay
APEM Inc
Analog Devices, Inc.
Analog Devices
Texas Instruments
Analog Devices
Analog Devices
FTDI
Analog Devices
Analog Devices
Winbond Electronics
NXP Semiconductors
Texas InstrumentsI
