The B9512G using a D8125 can use point of protection input transponder (POPIT) modules to
provide a maximum of 238 off-board points. The B8512G using a D8125 provides up to 91 off-
board points.
D9127 POPITs use the D8125 POPEX Module to report to the control panel. Each D8125
supports up to 119 POPIT points. Connect two D8125 modules to the B9512G to bring the
total number of POPIT points to 238.
–
–
The control panel annunciates activity only for each POPIT, not for each detection device
connected to the sensor loop.
D9127 Module enclosures are made of UL Listed fire resistant material. D9127T Modules
contain tamper switches, while D9127U Modules do not. UL requires D9127T Modules for
certificated installations.
Notice!
The expansion loop can be shared between fire and non-fire devices where the POPIT module
provides data isolation between the input and the expansion loop connections.
Installation
For detailed instructions, refer to the corresponding document listed in Related
documentation, page 13.
13.3.3

D8128D OctoPOPIT Eight-point Expander

The control panel supports the D8128D through the use of the B600.
The B600 supports up to 30 (thirty) D8128D modules. The B9512G supports up to 15 D8128D
modules connected to the B600 ZX1 terminals and up to 15 D8128D modules connected to
the B600 ZX2 terminals. The B8512G supports up to 12 D8128D modules connected to the
B600 ZX1 terminals (for the 12
are available).
Calculate power consumption
Make sure that there is enough power for the module and the other powered devices that you
want to connect to the system.
Refer to On-board outputs, page 65.
Caution!
Remove all power (AC and battery) before making any connections. Failure to do so might
!
result in personal injury and/or equipment damage.
The D8128D OctoPOPIT Module combines the functions of the D8125 POPEX Module and the
D9127 POPIT Modules to provide eight off-board points in a single module. You can wire both
D8128D OctoPOPIT and D8125 POPEX Modules in parallel to the B600 ZONEX module
terminals. The control panel supports the following number of modules through the B600:
–
–
Requirements for Fire Initiation applications
You can connect the D125B Dual Powered Loop Interface Module outputs directly to the point
inputs on the D8128D. Use the D125B to connect two-wire smoke detectors.
Bosch Security Systems, Inc.
Points 9 to 127 connect to the first D8125.
Points 129 to 247 connect to the second D8125.
B9512G. 30
B8512G. 12
th module, switches set for points 97-104, only points 97 to 99
