Brake system

Checking function of
brakes
Pull the right brake lever.
There is a clearly perceptible
pressure point.
Pull the left brake lever.
There is a clearly perceptible
pressure point.
To test the parking brake, ex-
tend the side stand and try to
push the E-Scooter forward
and back.
E-Scooter cannot be moved.
If a clear pressure point is not
perceptible or if the Scooter can
be pushed in either direction:
Have the brakes checked by
an authorised BMW Motorrad
dealer.
Checking front brake pad
thickness
Make sure the ground is level
and firm and place the E-
Scooter on its stand.
Visually inspect the brake pads
to ascertain their thickness.
Viewing direction: on left and
right between wheel and front
suspension toward brake
pads 1.
Brake-pad wear limit,
front
min 1.0 mm (Friction pad only,
without backing plate. The
wear indicators (grooves) must
be clearly visible.)
If the wear indicating marks are
no longer clearly visible:
